Cylindrical Spindle Bearing Replacement NN3010 NN3011 NN3012 Double Row No Cage

Name: Cylindrical Spindle Bearing Replacement NN3010 NN3011 NN3012 Double Row No Cage
Brand: Wuxi Handa Bearing Co., Ltd.
SKU: NN3010 NN3011 NN3012 NN3014K
Price: negotiable USD
Availability: InStock

All Products

Taper Roller Bearing
(33)

Spherical Roller Bearing
(28)

Cylindrical Roller Bearing
(29)

Deep Groove Ball Bearing
(25)

Angular Contact Ball Bearing
(13)

Pillow Block Bearing
(11)

Needle Roller Bearing
(10)

Thin Wall Bearing
(10)

SKF Ball Bearing
(12)

FAG Spherical Roller Bearing
(12)

TIMKEN Roller Bearing
(12)

NSK Ball Bearing
(12)

Certification

I'm Online Chat Now

Cylindrical Spindle Bearing Replacement NN3010 NN3011 NN3012 Double Row No Cage

Large Image : Cylindrical Spindle Bearing Replacement NN3010 NN3011 NN3012 Double Row No Cage

Product Details:

Place of Origin:	CHINA
Brand Name:	HDBB
Certification:	ISO9001 & GB307
Model Number:	NN3010 NN3011 NN3012 NN3014K

Payment & Shipping Terms:

Minimum Order Quantity:	10 Pcs
Packaging Details:	Industrial Packing Single Color Box OEM
Delivery Time:	5-7 Works days
Payment Terms:	T/T , Western Union, RMB
Supply Ability:	80,000 Pcs per Month

Contact Now

Cylindrical Spindle Bearing Replacement NN3010 NN3011 NN3012 Double Row No Cage

Description

Model:	NN3010 NN3011 NN3012 NN3014K	Type:	Cylindrical Roller Bearing
Row:	Double Rows	Size:	50x80x23mm
Material:	Chrome Steel Gcr15	Seal Type:	No Seal
Highlight:	Cylindrical Spindle Bearing Replacement , NN3011 Spindle Bearing Replacement , NN3010 Bearing

Cylindrical Roller Bearing NN3010 NN3011 NN3012 NN3014K Double Row No Cage For Machine Tool Spindles

This NN3010 TN/SP bearing is a double row super precision cylindrical roller bearing with a triple ribbed inner ring, a PA66 cage and a P5 accuracy class.. The bearing's dimensions are 50x80x23mm.

We can supply the following bearings :1 . Deep groove ball bearings (68 series , 69 series , 60 series , 62 series , 63 series , 64 series)
. Tapered roller bearing (320 series , 322 series , 323 series)
. Spherical ball bearing ( 230 series , 222 series , 223 series)
. Thrust ball bearing (511 series , 512 series , 513 series)
. Cylindrical roller bearing (NU10 series , NJ2 Series , N3 series , NN series )
. Angular contact ball bearing (70 series . 72 series . 73 series . 74 series)
. Pillow block bearing (UCP series , UCF series , UCT series , UCFL series)
. Needle roller bearing

DOUBLE ROW - NN30K Series :


			Boundary dimensions(mm)

			Basic load ratings(kN)

			Limiting speeds(rpm)

			Mass(Kg)

			Bearing Number

			d

			D

			B

			rs min

			Cr

			Cor

			Grease

			Oil

			(Approx.)

			Lanton Bearing

			25

			47

			16

			0.6

			25.8

			30

			14,000

			17,000

			0.124

			NN3005

			25

			47

			16

			0.6

			25.8

			30

			14,000

			17,000

			0.121

			NN3005K

			30

			55

			19

			1

			31

			37

			12,000

			15,000

			0.199

			NN3006

			30

			55

			19

			1

			31

			37

			12,000

			15,000

			0.193

			NN3006K

			35

			62

			20

			1

			38

			47.5

			11,000

			13,000

			0.242

			NN3007

			35

			62

			20

			1

			38

			47.5

			11,000

			13,000

			0.235

			NN3007K

			40

			68

			21

			1

			43.5

			55.5

			9,700

			11,000

			0.312

			NN3008

			40

			68

			21

			1

			43.5

			55.5

			9,700

			11,000

			0.303

			NN3008K

			45

			75

			23

			1

			52

			68.5

			8,800

			10,000

			0.405

			NN3009

			45

			75

			23

			1

			52

			68.5

			8,800

			10,000

			0.393

			NN3009K

			50

			80

			23

			1

			53

			72.5

			8,000

			9,400

			0.433

			NN3010

			50

			80

			23

			1

			53

			72.5

			8,000

			9,400

			0.419

			NN3010K

			55

			90

			26

			1.1

			69.5

			96.5

			7,300

			8,600

			0.651

			NN3011

			55

			90

			26

			1.1

			69.5

			96.5

			7,300

			8,600

			0.631

			NN3011K

			60

			95

			26

			1.1

			71

			102

			6,700

			7,900

			0.704

			NN3012

			60

			95

			26

			1.1

			71

			102

			6,700

			7,900

			0.683

			NN3012K

			65

			100

			26

			1.1

			75

			111

			6,200

			7,300

			0.758

			NN3013

			65

			100

			26

			1.1

			75

			111

			6,200

			7,300

			0.735

			NN3013K

			70

			110

			30

			1.1

			94.5

			143

			5,800

			6,800

			1.04

			NN3014

			70

			110

			30

			1.1

			94.5

			143

			5,800

			6,800

			1.01

			NN3014

Production Process :  10 steps

Factory and Warehouse :

Cylindrical Spindle Bearing Replacement NN3010 NN3011 NN3012 Double Row No Cage 4

Packing and Delivery :

Cylindrical Spindle Bearing Replacement NN3010 NN3011 NN3012 Double Row No Cage 5

Shipments :

1 . By Express: DHL, FEDEX, UPS, TNT, SF EXPRESS and EMS.

2 . By Air: We can ship from Shanghai, Shenzhen, Hongkong etc.

3 . By Sea: We can offer you FOB Shanghai, FOB Guangzhou etc.

4 . We can also send bearings to your forwarder or agent in China, who can arrange shipment for you.

Cylindrical Spindle Bearing Replacement NN3010 NN3011 NN3012 Double Row No Cage 6

Tag:

Single Row Cylindrical Roller Bearing,

FAG Cylinder Roller Bearing,

Theoretical Cylindrical Roller Bearing

Contact Details

Wuxi Handa Bearing Co., Ltd.

Contact Person: Ms. Marilyn Zhang

Tel: +86-17312783296

Fax: 86-510-8260-9866

Other Products

NJ321 NJ322 NJ324 Cylindrical Roller Bearing 120x260x55mm Engine Camshaft Bearing

Model: NJ321 NJ322 NJ324

Clearance: C0,C3,C4,C5

Structure: Cylindrical roller

Type: Single row

Cylindrical Heavy Duty Roller Bearing Rotating Bearings NJ Type NJ332 NJ334

Model: NJ332 NJ334

HS Code: 8482500090

Structure: Cylindrical

Vibration: V1 V2 V3 V4

NJ213 Cylindrical Roller Bearing Single Row 65x120x23mm NJ213ECM Weight 1.15kgs

Material: NJ213 NJ213ECM

Structure: Cylindrical

Type: Roller

Cage: ECP ECM EM

Double Row Roller Bearing NNF 5007 ADB-2LSV SL04 5008 PP SL04 5009 PP

Model: SL04 5007 PP SL04 5008PP SL04 5009 PP

Number of Row: Double Row

Rolling Element: Cylindrical Roller Bearing

Material: Hardened Alloy Steel

NJ326 NJ328 NJ330 Cylindrical Roller Bearing N328 140x300x62mm High Precision

Model: NJ326 NJ328 NJ330

Lubrication: Oil Grease

Structure: Cylindrical

Vibration: V1 V2 V3 V4

Boundary dimensions(mm)				Basic load ratings(kN)		Limiting speeds(rpm)		Mass(Kg)	Bearing Number
d	D	B	rs min	Cr	Cor	Grease	Oil	(Approx.)	Lanton Bearing
25	47	16	0.6	25.8	30	14,000	17,000	0.124	NN3005
25	47	16	0.6	25.8	30	14,000	17,000	0.121	NN3005K
30	55	19	1	31	37	12,000	15,000	0.199	NN3006
30	55	19	1	31	37	12,000	15,000	0.193	NN3006K
35	62	20	1	38	47.5	11,000	13,000	0.242	NN3007
35	62	20	1	38	47.5	11,000	13,000	0.235	NN3007K
40	68	21	1	43.5	55.5	9,700	11,000	0.312	NN3008
40	68	21	1	43.5	55.5	9,700	11,000	0.303	NN3008K
45	75	23	1	52	68.5	8,800	10,000	0.405	NN3009
45	75	23	1	52	68.5	8,800	10,000	0.393	NN3009K
50	80	23	1	53	72.5	8,000	9,400	0.433	NN3010
50	80	23	1	53	72.5	8,000	9,400	0.419	NN3010K
55	90	26	1.1	69.5	96.5	7,300	8,600	0.651	NN3011
55	90	26	1.1	69.5	96.5	7,300	8,600	0.631	NN3011K
60	95	26	1.1	71	102	6,700	7,900	0.704	NN3012
60	95	26	1.1	71	102	6,700	7,900	0.683	NN3012K
65	100	26	1.1	75	111	6,200	7,300	0.758	NN3013
65	100	26	1.1	75	111	6,200	7,300	0.735	NN3013K
70	110	30	1.1	94.5	143	5,800	6,800	1.04	NN3014
70	110	30	1.1	94.5	143	5,800	6,800	1.01	NN3014
